Pictures of the Month 2020

Iso-surfaces of Q-criterion are used to mark the secondary vortices and the boundary layer transition due to the boundary layer separation on the suction side. On the first vane the stream-wise vorticity is used to mark the zones where separation occurs.
September 2020
Master student Gerhard Erlacher proudly presents his 3D printed sector-cascade test rig of a turbine center frame with struts used for heat transfer and film cooling measurements
August 2020
The Institute team, who installed the new wind tunnel for turbine flow investigations, which went into operation in June 2020
July 2020
Prof. Heitmeir proudly presents our new wind tunnel for turbine flow investigations which is going into operation in June.
June 2020
On April 20 we resumed the work in our laboratories in strict adherence to Corona safety regulations.  Martin Haubenhofer and Florian Plank mount the piping for our new wind tunnel wearing face protection masks.
May 2020
April 2020
Research Assistant Philipp Bruckner receives a present for his newborn daughter Emilia from the colleagues of the institute. Congratulations and all the best!
March 2020
February 2020
Master student Marian Staggl (left) investigates the flow through a human nose with the support of our research assistants Manual Zenz and Felix Greiffenhagen. The experimental setup is on the bottom right.
January 2020
