Nikola Tesla Labor - Internal View

Nikola Tesla Labor - Internal View

Test systems
in the big high voltage laboratory

AC ................................. 1500 kV / 1500 kVA
Lightning impulse...... ± 2500 kV / 165 kJ
Switching impulse .... ± 1900 kV / 165 kJ
DC ................................. ± 1500 kV / 20 mA
Dimensions ................ 35 m x 25 m x 21 m

HV - com²

HV - com²

Support for standardisation of high voltage testing with composite and combined wave shapes 19NRM07 HV-com²

more...

Welcome to the
Institute of High Voltage Engineering and System Performance
of Graz University of Technology

Besides lectures and research work, the institute is also working on high voltage tests and analysis, focused on the assessment and development of high voltage equipment and systems.

  IHS.TUGraz
  © Pictures TU Graz/IHS
